AMR-Mini Compact Microplate Reader, 96-Well, Bluetooth / USB
SKU: AS-16070-00
The AMR-Mini is an ultra-compact 96-well absorbance microplate reader, about the size of two microplates. It measures endpoint and kinetic assays with a long-life LED light source, and connects by Bluetooth or USB to a PC or app, making it ideal for tight benches, modular workstations, anaerobic chambers or incubators.
- Very small footprint: 135 x 225 x 89 mm and only 2 kg.
- Multiple detection modes: single wavelength, dual wavelength and kinetics.
- Long-life LED light source: energy-saving, maintenance free, with a reference optical path for stable data.
- Swappable filters: removable light source and filter module with 450/630 nm and 405/492 nm included; other wavelengths can be fitted.
- Fast: reads a 96-well plate in under 15 seconds at a single wavelength.
Catalogue number AS-16070-00.
Technical Specifications
- Model: AMR-Mini (catalogue no. AS-16070-00)
- Detection: endpoint and kinetic; single wavelength, dual wavelength
- Plate: 96-well
- Light source: LED; detector: 9 photodiodes with reference optical path
- Wavelength range: 400-750 nm; accuracy within ±2 nm
- Standard filters: 450/630 nm and 405/492 nm; other wavelengths available as optional filters
- Measuring range: 0-4 Abs; resolution 0.001 Abs
- Linearity: R² ≥ 0.995 from 0.0 to 3.0 Abs
- Accuracy: within ±(0.5% + 0.01 Abs) from 0.0 to 2.0 Abs
- Repeatability: CV 0.5% or better (below 3 Abs)
- Measuring speed: under 15 s per plate (single wavelength); under 28 s (dual wavelength)
- Software: app and PC software (Windows 7 / 10, 64-bit); Chinese / English interface
- Connection: Bluetooth or USB cable; ports: 1 x Type-C, 1 x USB A, 1 x USB B
- Power input: Type-C, 12 V, 3 A
- Dimensions (W x D x H): 135 x 225 x 89 mm
- Weight: 2 kg
$4,599.00Price
